EX400II06-51L-A01 is a 40” TFT Liquid Crystal Display module with LED Backlight unit and 2ch-LVDS interface. This module supports 1920 x 1080 Full HDTV format and can display 16.7M colors (8-bit).
No. | Item | Specification |
1 | LCD size | 40 inch |
2 | Resolution | 1920 x3(RGB)X1080 |
3 | Display mode | Normally Black, Transmissive |
4 | Pixel pitch | 0.15245 (H) x 0.4494 (V) mm |
5 | Active area | 878.112 (H) x 485.352 (V) mm |
6 | Module size | 895.9(H)X511.7(V)X20.1(D) mm |
7 | Pixel arrangement | RGB-vertical stripe |
8 | Interface | 2ch-LVDS |
9 | Surface treatment | Anti-Glare coating (Haze 1%) |
